Upload files to a Woo publication

A Woo publication without files is metadata without evidence. In this tutorial you attach documents to a Woo publication through four upload modes: one file, multiple files at once, and large files in chunks. Plus publish, unpublish, and clean up.

In the examples we use:

• Host: http://localhost:8080
• Auth: admin:admin
• Register slug: woo
• Schema slug: onderzoeksrapporten
• Object UUID: 3422e6cd-1ba5-478c-b842-8f206f9d7358

Replace the object UUID with your own.

The base pattern

All files are attached to a specific object. The URL always follows the same pattern:

POST /index.php/apps/openregister/api/objects/{register}/{schema}/{id}/files

OpenRegister automatically creates a folder for the object under Open Registers/{Register Title}/{Object UUID}/. All files land there. The folder appears as soon as you upload the first file.

Mode 1: one file via JSON and base64

The simplest route, fine for small documents up to a few megabytes:

OBJ=3422e6cd-1ba5-478c-b842-8f206f9d7358
B64=$(echo "Report content." | base64 -w0)

curl -u admin:admin \
  -X POST "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/files" \
  -H "OCS-APIRequest: true" \
  -H "Content-Type: application/json" \
  -d "{
    \"name\": \"rapport-2026.txt\",
    \"content\": \"$B64\",
    \"share\": true
  }"

The response:

{
  "id": 3306,
  "path": "/admin/files/Open Registers/Woo Register/3422e6cd-.../rapport-2026.txt",
  "title": "rapport-2026.txt",
  "accessUrl": "http://localhost:8080/index.php/s/CH5JsTKtrczyQgw",
  "downloadUrl": "http://localhost:8080/index.php/s/CH5JsTKtrczyQgw/download",
  "type": "text/plain",
  "size": 44,
  "hash": "4bdf3a838bc59f367824ad59a14630c0",
  "published": "1970-01-01T00:00:00+00:00",
  "labels": [],
  "object": "3422e6cd-..."
}

share: true creates a public share link right away. The accessUrl is then the public landing URL. If you want to keep the file private for now, leave share out or set it to false.

When to use it: scripts and synchronisations where you generate text content, small PDFs, or CI pipelines. When not: files above a few MB. Base64 makes the payload 33% larger and you quickly hit the PHP post_max_size limit.

Mode 2: one binary file via multipart

For binary files (PDF, DOCX, images) you use the filesMultipart endpoint. It avoids the base64 overhead and is faster for mid-size files.

OBJ=3422e6cd-1ba5-478c-b842-8f206f9d7358

curl -u admin:admin \
  -X POST "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/filesMultipart" \
  -H "OCS-APIRequest: true" \
  -F "files[]=@/path/to/rapport.pdf" \
  -F "share=true"

The response is an array with one element:

[
  {
    "id": 3307,
    "path": "/admin/files/Open Registers/Woo Register/3422e6cd-.../rapport.pdf",
    "title": "rapport.pdf",
    "type": "application/pdf",
    "size": 482310,
    "hash": "a4abb3649eff2d9ba4f80675371a56b8",
    "object": "3422e6cd-..."
  }
]

files[] works for one file and for multiple files. The endpoint also accepts a single file= field, but files[] is more consistent. The exact same call scales to Mode 3 below without changing your field name.

Mode 3: multiple files in one request

The filesMultipart endpoint accepts multiple files in a single request. One HTTP call, one transaction, one response array. Handy for publications with multiple attachments.

OBJ=3422e6cd-1ba5-478c-b842-8f206f9d7358

curl -u admin:admin \
  -X POST "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/filesMultipart" \
  -H "OCS-APIRequest: true" \
  -F "files[]=@/path/to/attachment-1.pdf" \
  -F "files[]=@/path/to/attachment-2.pdf" \
  -F "files[]=@/path/to/attachment-3.pdf" \
  -F "share=true"

Response:

[
  { "id": 3308, "title": "attachment-1.pdf", "size": 29, "hash": "b753b747...", ... },
  { "id": 3309, "title": "attachment-2.pdf", "size": 32, "hash": "f370ad27...", ... },
  { "id": 3310, "title": "attachment-3.pdf", "size": 28, "hash": "80a9a215...", ... }
]

Every file gets its own entry in the response. The share flag applies to the whole batch. All files go public at the same time, or all stay private at the same time.

Practical limit: PHP's post_max_size is usually 100 MB. The total of all files in one request must stay under that. For larger uploads, jump to Mode 4.

Mode 4: large files in chunks via WebDAV

For files above the PHP upload limit (typically 100 MB) you split them into chunks and send them via Nextcloud's WebDAV chunked upload protocol. After that you move the assembled file to the object folder.

This is the same protocol the Nextcloud web client and desktop app use. It works for any file size and adapts to network interruptions.

Step 4.1: create a transfer folder

Give the transfer a unique ID, for example a timestamp:

TRANSFER_ID="woo-chunked-$(date +%s)"
DAV_BASE="http://localhost:8080/remote.php/dav"

curl -u admin:admin \
  -X MKCOL "$DAV_BASE/uploads/admin/$TRANSFER_ID"

A 201 means the transfer folder is ready.

Step 4.2: split the file and upload the chunks

We split a 6 MB test file into three 2 MB chunks:

split -b 2M /path/to/large-report.pdf /tmp/chunk-

i=1
for chunk in /tmp/chunk-*; do
  CHUNK_NUM=$(printf "%05d" $i)
  curl -u admin:admin \
    -X PUT --data-binary "@$chunk" \
    "$DAV_BASE/uploads/admin/$TRANSFER_ID/$CHUNK_NUM"
  i=$((i+1))
done

Chunks get five-digit numbers (00001, 00002, 00003). Keep the order in the file names, because Nextcloud assembles based on it.

Step 4.3: assemble and place in the object folder

A MOVE call combines the chunks into one file at the final location:

OBJ=3422e6cd-1ba5-478c-b842-8f206f9d7358
DEST="$DAV_BASE/files/admin/Open%20Registers/Woo%20Register/$OBJ/large-report.pdf"
TOTAL_LENGTH=$(wc -c < /path/to/large-report.pdf)

curl -u admin:admin \
  -X MOVE "$DAV_BASE/uploads/admin/$TRANSFER_ID/.file" \
  -H "Destination: $DEST" \
  -H "OC-Total-Length: $TOTAL_LENGTH"

A 201 means the file is at its destination. OpenRegister picks it up automatically. As soon as you ask for the files list of the object, the file shows up.

Step 4.4: verify in OpenRegister

curl -u admin:admin \
  "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/files" \
  -H "OCS-APIRequest: true"

You see the new file at its real size:

{
  "id": 3316,
  "path": "/admin/files/Open Registers/Woo Register/3422e6cd-.../large-report.pdf",
  "title": "large-report.pdf",
  "size": 6291456,
  "hash": "d7d7eec53f6d70d1bdceea08c10d0bb1",
  "modified": "2026-05-07T05:14:34+00:00"
}

Important: chunks have to go to the folder of the current user (admin in this example). For a service account, upload into that account first. The MOVE then places the file in the shared register folder.

Publish and unpublish

An uploaded file is not public by default (accessUrl: null). For Woo publications you want to choose explicitly which files are public and which are not, for example because an attachment is privacy-sensitive and has to be redacted first.

Make public:

FID=3306
curl -u admin:admin \
  -X POST "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/files/$FID/publish" \
  -H "OCS-APIRequest: true"

The response now has an accessUrl:

{
  "id": 3306,
  "title": "rapport-2026.txt",
  "accessUrl": "http://localhost:8080/index.php/s/CH5JsTKtrczyQgw",
  "downloadUrl": "http://localhost:8080/index.php/s/CH5JsTKtrczyQgw/download"
}

Make private again:

curl -u admin:admin \
  -X POST "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/files/$FID/depublish" \
  -H "OCS-APIRequest: true"

After unpublishing, accessUrl and downloadUrl are null again and the share link is revoked.

List, download, delete

Action	Method	URL
List of files on an object	GET	/api/objects/{register}/{schema}/{id}/files
Detail of one file	GET	/api/objects/{register}/{schema}/{id}/files/{fileId}
Download (all files as zip)	GET	/api/objects/{register}/{schema}/{id}/files/download
Download directly by id	GET	/api/files/{fileId}/download
Delete one file	DELETE	/api/objects/{register}/{schema}/{id}/files/{fileId}

Example for a list:

curl -u admin:admin \
  "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/files" \
  -H "OCS-APIRequest: true"

Delete one file:

curl -u admin:admin \
  -X DELETE "http://localhost:8080/index.php/apps/openregister/api/objects/woo/onderzoeksrapporten/$OBJ/files/3306" \
  -H "OCS-APIRequest: true"

Which mode do you pick when?

Mode	Best for	Limit	Code complexity
1. JSON + base64	Server-to-server scripts, small PDFs	About 75 MB raw content (33% overhead on post_max_size)	Low
2. Multipart, one file	Browser uploads, regular PDFs and DOCX	post_max_size, usually 100 MB	Low
3. Multipart, multiple files	Publications with multiple attachments	Sum of files under post_max_size	Low
4. WebDAV chunked + MOVE	Video, scans, datasets above 100 MB	No practical upper bound	High

For most Woo publications you pick Mode 2 or 3. The moment a file larger than 100 MB shows up, you switch to Mode 4.

Troubleshooting

!The uploaded file exceeds upload_max_filesize

Raise upload_max_filesize and post_max_size in php.ini, or switch to Mode 4.

!File does not appear in the /files list after MOVE

Check that the Destination header points to Open Registers/{Register Title}/{Object UUID}/ and that the UUID matches an existing object. OpenRegister scans only that folder.

!accessUrl stays null after publish

Check that share links are enabled in the Nextcloud admin (Settings -> Sharing -> "Allow apps to use the share API"). Without this setting, publications cannot get a public link.
